LAVS series

The LAVS series of air/water heat pumps from NOVELAN impresses with its flexibility, simplicity and in terms of efficiency and sound - and all this with minimal installation effort, whether in a new building or when replacing an existing heating system.

Benefits

All in one compact device

Cost-effective heating, pleasant cooling and well-tempered domestic hot water: That's exactly what you can do with the LAVS series heat pumps.

Latest inverter technology

Thanks to inverter technology, LAVS units adapt optimally to the individual needs of users and homeowners, thus forming a flexible system solution - whether in a new building or in the course of a refurbishment.

Low space requirement inside the building

Due to the outdoor installation of LAVS air/water heat pumps, they are the optimal solution for those who would like to use their basement for something else or do not have one at all.

  • Item number 103778WR2141
  • Product group AIR/WATER
  • Heating capacity 1 3,82 (A2/W35 part. load) kW
  • Heating capacity 2 2,81 (A7/W35 part. load) kW
  • COP 1 4,19 (A2/W35 part. load)
  • COP 2 5,03 (A7/W35 part. load)
  • Max. flow temperature 60 °C
  • Indoor / Outdoor installation Outdoor installation
  • Cooling Yes
  • Refrigerant R410A
  • Energy efficiency class space heating 35°C (combi heater) A+++
  • Energy efficiency class space heating 55°C (combi heater) A++
  • Energy efficiency class space heating 55°C (combined system) A++
  • Manual_LAVS_gUK.pdf
  • Controller_WPR_20_21_Teil1_lEN.pdf
  • Controller_WPR_21_Teil2_kEN.pdf
  • Item number 103779WR2141
  • Product group AIR/WATER
  • Heating capacity 1 5,00 (A2/W35 part. load) kW
  • Heating capacity 2 5,29 (A7/W35 part. load) kW
  • COP 1 4,01 (A2/W35 part. load)
  • COP 2 4,71 (A7/W35 part. load)
  • Max. flow temperature 60 °C
  • Indoor / Outdoor installation Outdoor installation
  • Cooling Yes
  • Refrigerant R410A
  • Energy efficiency class space heating 35°C (combi heater) A++
  • Energy efficiency class space heating 55°C (combi heater) A++
  • Energy efficiency class space heating 55°C (combined system) A++
  • Manual_LAVS_gUK.pdf
  • Controller_WPR_20_21_Teil1_lEN.pdf
  • Controller_WPR_21_Teil2_kEN.pdf
  • Item number 103778HV941
  • Product group AIR/WATER
  • Heating capacity 1 3,82 (A2/W35 part. load) kW
  • Heating capacity 2 2,81 (A7/W35 part. load) kW
  • COP 1 4,19 (A2/W35 part. load)
  • COP 2 5,03 (A7/W35 part. load)
  • Max. flow temperature 60 °C
  • Indoor / Outdoor installation Outdoor installation
  • Cooling Yes
  • Refrigerant R410A
  • Energy efficiency class space heating 35°C (combi heater) A+++
  • Energy efficiency class space heating 55°C (combi heater) A++
  • Energy efficiency class space heating 55°C (combined system) A++
  • Manual_LAVS_gUK.pdf
  • Controller_WPR_20_21_Teil1_lEN.pdf
  • Controller_WPR_21_Teil2_kEN.pdf
  • Item number 103778HV1241
  • Product group AIR/WATER
  • Heating capacity 1 3,82 (A2/W35 part. load) kW
  • Heating capacity 2 2,81 (A7/W35 part. load) kW
  • COP 1 4,19 (A2/W35 part. load)
  • COP 2 5,03 (A7/W35 part. load)
  • Max. flow temperature 60 °C
  • Indoor / Outdoor installation Outdoor installation
  • Cooling Yes
  • Refrigerant R410A
  • Energy efficiency class space heating 35°C (combi heater) A+++
  • Energy efficiency class space heating 55°C (combi heater) A++
  • Energy efficiency class space heating 55°C (combined system) A++
  • Manual_LAVS_gUK.pdf
  • Controller_WPR_20_21_Teil1_lEN.pdf
  • Controller_WPR_21_Teil2_kEN.pdf
  • Item number 103779HV1241
  • Product group AIR/WATER
  • Heating capacity 1 5,00 (A2/W35 part. load) kW
  • Heating capacity 2 5,29 (A7/W35 part. load) kW
  • COP 1 4,01 (A2/W35 part. load)
  • COP 2 4,71 (A7/W35 part. load)
  • Max. flow temperature 60 °C
  • Indoor / Outdoor installation Outdoor installation
  • Cooling Yes
  • Refrigerant R410A
  • Energy efficiency class space heating 35°C (combi heater) A++
  • Energy efficiency class space heating 55°C (combi heater) A++
  • Energy efficiency class space heating 55°C (combined system) A++
  • Manual_LAVS_gUK.pdf
  • Controller_WPR_20_21_Teil1_lEN.pdf
  • Controller_WPR_21_Teil2_kEN.pdf
  • Item number 103778HSV941
  • Product group AIR/WATER
  • Heating capacity 1 3,82 (A2/W35 part. load) kW
  • Heating capacity 2 2,81 (A7/W35 part. load) kW
  • COP 1 4,19 (A2/W35 part. load)
  • COP 2 5,03 (A7/W35 part. load)
  • Max. flow temperature 60 °C
  • Indoor / Outdoor installation Outdoor installation
  • Cooling Yes
  • Refrigerant R410A
  • Energy efficiency class space heating 55°C (combi heater) A++
  • Energy efficiency class hot water preparation (combi boiler) A
  • Energy efficiency class space heating 55°C (combined system) A++
  • Energy efficiency class hot water preparation (combined system) A
  • Manual_LAVS_gUK.pdf
  • Controller_WPR_20_21_Teil1_lEN.pdf
  • Controller_WPR_21_Teil2_kEN.pdf
  • Item number 103778HSV12141
  • Product group AIR/WATER
  • Heating capacity 1 3,82 (A2/W35 part. load) kW
  • Heating capacity 2 2,81 (A7/W35 part. load) kW
  • COP 1 4,19 (A2/W35 part. load)
  • COP 2 5,03 (A7/W35 part. load)
  • Max. flow temperature 60 °C
  • Indoor / Outdoor installation Outdoor installation
  • Cooling Yes
  • Refrigerant R410A
  • Energy efficiency class space heating 55°C (combi heater) A++
  • Energy efficiency class hot water preparation (combi boiler) A
  • Energy efficiency class space heating 55°C (combined system) A++
  • Energy efficiency class hot water preparation (combined system) A
  • Manual_LAVS_gUK.pdf
  • Controller_WPR_20_21_Teil1_lEN.pdf
  • Controller_WPR_21_Teil2_kEN.pdf
  • Item number 103779HSV12141
  • Product group AIR/WATER
  • Heating capacity 1 5,00 (A2/W35 part. load) kW
  • Heating capacity 2 5,29 (A7/W35 part. load) kW
  • COP 1 4,01 (A2/W35 part. load)
  • COP 2 4,71 (A7/W35 part. load)
  • Max. flow temperature 60 °C
  • Indoor / Outdoor installation Outdoor installation
  • Cooling Yes
  • Refrigerant R410A
  • Energy efficiency class space heating 55°C (combi heater) A++
  • Energy efficiency class hot water preparation (combi boiler) A
  • Energy efficiency class space heating 55°C (combined system) A++
  • Energy efficiency class hot water preparation (combined system) A
  • Manual_LAVS_gUK.pdf
  • Controller_WPR_20_21_Teil1_lEN.pdf
  • Controller_WPR_21_Teil2_kEN.pdf
